Lenze 8200 - Page 231

Configuration
8200SHB0199
7-93
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C125¤* LECOMbaud rate -0- -0- 9600 baud
-1- 4800 baud
-2- 2400 baud
-3- 1200 baud
-4- 19200 baud
Only for LECOM
applications
C126* Selection of
communication fault
-0- -0- No TRIP when stopping the
communication in the process
channel
-1- TRIP (-CEO-) when stopping the
communication in the process
channel
O
n
l
y
f
o
r
b
u
s
o
p
e
r
a
t
i
o
n
C127 Choice
Set-value input
-0- -0- Absolute setpoint selection in Hz via
C046 or process channel
-1- Normalised setpoint selection via
C141 (0 ... 100 %) or process
channel ( 16384 = f
dmax
(C011))
O
n
l
y
f
o
r
b
u
s
o
p
e
r
a
t
i
o
n
C135* Control word See Operating
Instructions 2102
C141* Standardised
setpoint
-100.00 {0.01 %} 100.00 Only for bus operation
Only when C127 = 1
active
C142¤ Start condition -1- -0- Automatic start inhibited,
flying-restart circuit not active
-1- Automatic start, if term. 28 HIGH,
flying-restart circuit not active
-2- Automatic start inhibited,
flying-restart circuit active
-3- Automatic start, if term. 28 HIGH,
flying-restart circuit active
Page 7-49
C144¤ Chopper frequency
r
e
d
u
c
t
i
o
n
-1- -0- No chopper-frequency reduction
-
1
-
A
u
t
o
m
a
t
i
c
c
h
o
p
p
e
r
f
r
e
q
u
e
n
c
y
Page 7-29
r
e
d
u
c
t
i
o
n
-
1
-
A
u
t
o
m
a
t
i
c
c
h
o
p
p
e
r
f
r
e
q
u
e
n
c
y
reduction at J
max
-10C
C150* Status word See Operating
Instructions 2102
C156* Current threshold 0 0 {1 %} 150 Page 7-65
E.g. with
belt monitoring
C161* Actual fault Page 8-2
C162* Last fault Page 8-2
D
i
s
p
l
a
y
o
n
l
y
C163* Last but one fault Page 8-2
D
i
s
p
l
a
y
o
n
l
y
C164* Last but two fault Page 8-2
C170¤ TRIP-reset selection -0- TRIP reset by pressing the STP key
or LOW signal at ctrl. enable or
fieldbus
-1- Auto TRIP reset or TRIP reset by
pressing the STP key or LOW signal
at ctrl. enable or fieldbus
Page 8-4
C171 Deceleration for
Auto-TRIP reset
0.00 0.00 {0.01 s} 60.00 Page 8-4
C178* Operating time Page 7-64
D
i
s
p
l
a
y
o
n
l
y
C179* Mains connection
time
Page 7-64
Display only
C181* Setpoint PID
controller
0.00 -480.00 {0.02 Hz} 480.00 Page 7-34,
7-38
Only with C181  0
active
