Lenze 8200 - Page 230

Configuration
8200SHB01997-92
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C115¤ Priority mask digital
inputs
-0- E4 E3 E2 E1
-0-0 000
-1-0 001
-2-0 010
-3-0 011
-4-0 100
-5-0 101
-6-0 110
-7-0 111
-8-1 000
-9-1 001
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
Page 7-53 0: Function Ex
depends on C001
1: Function Ex is
independent of C001
- Ctrl. inhibit and TRIP
reset always have
first priority.
- With - 0- also TRIP
set and QSP have
priority.
C117¤
Function relay K2
-0- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
=0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature (J
max
-10C)
-10- TRIP or Q
min
or IMP
Page 7-65 ff
822X/824X -11- PTC warning
-12- Apparent motor current
(C054)< threshold C156
-13- Apparent motor current
(C054)< current threshold C156
and f
d
>Q
min
threshold (C017)
-14- Apparent motor current
(C054)< threshold C156 andinput
of ramp function generator =
output of ramp function generator
822X/824X -15- Warning motor phase failure
-16- f
d
(C050)< f
dmin
(C010)
C119¤ Function PTC
822X/824X
-0- -0- PTC input not active
-1- PTC input active, TRIP and pulse
inhibit will be set
-2- PTC input active
Wa rni ng
Page 7-72
C120
I
2
ktswitch-off Page 7-71
C
1
2
0
822X/824X 0 0 {1 %} 100 If C120 = 0, the
function is not active
