Lenze 8200 - Page 229

Configuration
8200SHB0199
7-91
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C111¤ Monitor signal -0-
-0- Field frequency
-1- Unit load
-2- Motor current
-3- DC-bus voltage
-4- Motor power
-5- Motor voltage
-6- Analog output 1/f
d
(1/C050)
-7- Field frequency of
f
dmin
(C010)... f
dmax
(C011)
-8- Actual PID controller value
Page 7-69 Selection -9- ... -25-
corresponds to the
relay output functions
C008 and C117:
- LOW = 0 V
- HIGH = 10 V
-9- Ready for operation
-10- TRIP fault message
-11- Motor is running
-12- Motor is running / CW rotation
-13- Motor is running / CCW rotation
-14- Field frequency f
d
=0
-15- f
dset
reached
-16- Q
min
reached
-17- I
max
reached
-18- Overtemperature (Ô
max
-10)
-19- TRIP, Q
min
or IMP set
822X/824X -20- PTC warning
-21- Apparent motor current
(C054)< current threshold (C156)
-22- Apparent motor current
(C054)< current threshold (C156)
and f
d
>Q
min
threshold
-23- Apparent motor current
(C054)< threshold (C156)and
input of ramp function generator =
output of ramp function generator
822X/824X -24- Warning motor phase failure
-25- f
d
(C050)< f
dmin
(C010)
C114¤ Signal level digital
inputs
-0- E4 E3 E2 E1
-0-0 000
-1-0 001
-2-0 010
-3-0 011
-4-0 100
-5-0 101
-6-0 110
-7-0 111
-8-1 000
-9-1 001
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
Page 7-52 0: Ex is not inverted
1: Ex is inverted
