Lenze 8200 - Page 228

Configuration
8200SHB01997-90
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C070 Gain PID controller 1.00 0.00 {0.01} 300.00 Page 7-34 0.0 = P-component
not active
C071 Integral action time
PID controller
100 10 9999 Page 7-34 9999 = I-component
not active
C072 Differential
componentofPID
controller
0.0 0.0 {0.1} 5.0 Page 7-34 0.0 = D-component
not active
C074 Influence PID
controller
0.0 0.0 {0.1 %} 100.0 Page 7-34
C077* Gain I
max
controller 0.25 0.00 {0.01} 1.00 Page 7-18
C078* Integral action time
I
max
controller
65 12 {1 ms} 9990 Page 7-18
C079
Oscillation damping * Page 7-31
C
0
7
9
822X/824X 5 0 {1} 80
C088 Rated motor current * 0 {1 A} 480
0.0 ... 2.0 k rated output current
Page 7-27
*depends on the unit
C091 Motor cos j *
0.4 {0.1} 1.0
Page 7-27
C093*
Type Page 7-64
C
0
9
3
*
821X 821X
822X 822X
Display only
824X 824X
D
i
s
p
l
a
y
o
n
l
y
C099* Software version 82 3x (Software 3x) Page 7-64
C105 Deceleration time
QSP
5.00 0.00 {0.02 s} 1300.00
Page 7-55
C106 Holding time for
autom. DC injection
brake
0.02 0.00 {0.01 s} 999.00 Page 7-56
C108* Gain (C111) 128 0 {1} 255 Page 7-69
