Parameter Name / value range / [default seng] Info
0x1400:002 PDO_RxCommParam_00h_REC: MappingVersion_U8
•
Read only
Display of the version of the RPDO1 mapping.
0x1600:001 ...
0x1600:016
PDO_RxMappParam_00h_REC: ObjectMapping_U64
1 ... ObjectMapping_U64 16
0 ... [0] ... 18446744073709552000
Mapping entries 1 ... 16 for RPDO1.
0x1800:001 PDO_TxCommParam_00h_REC: NodeID_U8
•
Read only
Display of the node ID of the TPDO1 receiver.
0x1800:002 PDO_TxCommParam_00h_REC: MappingVersion_U8
•
Read only
Display of the TPDO1 mapping version.
0x1A00:001 ...
0x1A00:016
PDO_TxMappParam_00h_REC: ObjectMapping_U64
1 ... ObjectMapping_U64 16
0 ... [0] ... 18446744073709552000
Mapping entries 1 ... 16 for TPDO1.
0x1C0A:001 DLL_CNCollision_REC: CumulaveCnt_U32
•
Read only
Display of the number of "collision" errors detected by the controlled
node.
•
The counter content is increased each me by 1 if the controlled node
has detected a "collision" error.
0x1C0B:001 DLL_CNLossSoC_REC: CumulaveCnt_U32
•
Read only
Display of the number of SoC losses detected by the controlled node.
•
The counter content is increased each me by 1 if the controlled node
has detected an SoC loss.
0x1C0B:002 DLL_CNLossSoC_REC: ThresholdCnt_U32
•
Read only
Display of the network quality with regard to SoC losses.
•
The counter content is increased each me by 8 if the controlled node
has detected an SoC loss and decreased by 1 at every error-free cycle.
0x1C0B:003 DLL_CNLossSoC_REC: Threshold_U32
0 ... [0] ... 4294967295
Error threshold for monitoring SoC losses.
•
If the counter content displayed in 0x1C0B:002 reaches the set thresh-
old, the error response selected in 0x2859:011 is eected.
•
If the seng is "0", this monitoring is not acve.
0x1C0F:001 DLL_CNCRCError_REC: CumulaveCnt_U32
•
Read only
Display of the number of CRC errors detected by the controlled node.
•
The counter content is increased each me by 1 if the controlled node
has detected a "CRC" error.
0x1C0F:002 DLL_CNCRCError_REC: ThresholdCnt_U32
•
Read only
Display of the network quality with regard to CRC errors.
•
The counter content is increased each me by 8 if the controlled node
has detected a CRC error and decreased by 1 at every error-free cycle.
0x1C0F:003 DLL_CNCRCError_REC: Threshold_U32
0 ... [0] ... 4294967295
Error threshold for monitoring CRC errors.
•
If the counter content displayed in 0x1C0F:002 reaches the set thresh-
old, the error response selected in 0x2859:010 is eected.
•
If the seng is "0", this monitoring is not acve.
0x1C10 DLL_CNLossOfLinkCum_U32
•
Read only
Display of the number of connecon losses detected by the controlled
node.
•
The counter content is increased each me by 1 if the controlled node
has detected a connecon loss.
•
A connecon loss may occur if the connecon is interrupted, for
instance due to a cable break/unplugging the network cable or a
defect hub/switch in the POWERLINK network.
0x1E40:001 NWL_IpAddrTable_0h_REC: IfIndex_U16
•
Read only
Display of the LF index which clearly idenes the Ethernet interface.
0x1E40:002 NWL_IpAddrTable_0h_REC: Addr IPAD
•
Read only
Display of the IP address of the Ethernet interface.
0x1E40:003 NWL_IpAddrTable_0h_REC: NetMask_IPAD
•
Read only
Display of the network mask of the Ethernet interface.
0x1E40:004 NWL_IpAddrTable_0h_REC: ReasmMaxSize_U16
•
Read only
Display of the maximum frame size which can be reconstructed by
frames that arrive in a fragmented way.
0x1E40:005 NWL_IpAddrTable_0h_REC: DefaultGateway_IPAD
0 ... [0] ... 4294967295
Display of the IP address of the router that connects the POWERLINK
segment to the higher-level network.
0x1E4A:001 NWL_IpGroup_REC: Forwarding_BOOL
•
Read only
Display whether the IP router funcon ("Forwarding") is supported or
not.
0x1E4A:002 NWL_IpGroup_REC: DefaultTTL_U16
0 ... [64] ... 65535
Time-to-live value which is entered into the IP header of frames to be
sent.
•
If the frame passes a router or a gateway, the me-to-live value in the
IP header is reduced by 1. As soon as the value is set to 0, the frame is
not valid anymore and is discarded.
