Address Designaon Default seng Category Data type Factor A M
0x1F82 NMT_FeatureFlags_U32 - (Read only) POWERLINK U32 1 X -
0x1F83 NMT_EPLVers_U8 - (Read only) POWERLINK U8 1 X -
0x1F8C NMT_CurrState_U8 - (Read only) POWERLINK U8 1 X -
0x1F8D:001 ...
0x1F8D:254
NMT_MNPResPayloadList: PResPayload 1 ... PRe-
sPayload 254
0 POWERLINK U16 1 X -
0x1F93:001 NMT_EPLNodeID_REC: NodeID_U8 - (Read only) POWERLINK U8 1 X -
0x1F93:002 NMT_EPLNodeID_REC: NodeIDByHW_BOOL - (Read only) POWERLINK U8 1 X -
0x1F93:003 NMT_EPLNodeID_REC: SWNodeID_U8 0 POWERLINK U8 1 X -
0x1F98:001 NMT_CycleTiming_REC: IsochrTxMaxPayload_ U16 - (Read only) POWERLINK U16 1 X -
0x1F98:002 NMT_CycleTiming_REC: IsochrRxMaxPayload_ U16 - (Read only) POWERLINK U16 1 X -
0x1F98:003 NMT_CycleTiming_REC: PResMaxLatency_U32 x ns (Read only) POWERLINK U32 1 X -
0x1F98:004 NMT_CycleTiming_REC: PReqActPayload_U16 0 POWERLINK U16 1 X -
0x1F98:005 NMT_CycleTiming_REC: PResActPayload_U16 0 POWERLINK U16 1 X -
0x1F98:006 NMT_CycleTiming_REC: ASndMaxLatency_U32 x ns (Read only) POWERLINK U32 1 X -
0x1F98:007 NMT_CycleTiming_REC: MulpleCycleCnt_U8 0 POWERLINK U8 1 X -
0x1F98:008 NMT_CycleTiming_REC: AsyncMTUSize_U16 0 POWERLINK U16 1 X -
0x1F98:009 NMT_CycleTiming_REC: Prescaler_U16 0 ns POWERLINK U16 1 X -
0x1F99 NMT_CNBasicEthernetTimeout_u32 0 POWERLINK U32 1 X -
0x1F9A NMT_HostName_VSTR POWERLINK STRING[32] 1 X -
0x1F9B:001 ...
0x1F9B:100
NMT_MulplCycleAssign_AU8: NMT_MulplCy-
cleAssign_AU8 1 ... NMT_MulplCycleAssign_AU8
100
- (Read only) POWERLINK U8 1 X -
0x1F9E NMT_ResetCmd_U8 - (Read only) POWERLINK U8 1 X -
0x2000:001
(P190.01)
Device data: Product code - (Read only) general STRING[18] 1 - -
0x2000:002
(P190.02)
Device data: Serial number - (Read only) general STRING[50] 1 - -
0x2000:004
(P190.04)
Device data: CU rmware version - (Read only) general STRING[50] 1 - -
0x2000:005
(P190.05)
Device data: CU rmware type - (Read only) general STRING[50] 1 - -
0x2000:006
(P190.06)
Device data: CU bootloader version - (Read only) general STRING[50] 1 - -
0x2000:007
(P190.07)
Device data: CU bootloader type - (Read only) general STRING[50] 1 - -
0x2000:008
(P190.08)
Device data: Object directory version - (Read only) general U32 1 - -
0x2000:010
(P190.10)
Device data: PU rmware version - (Read only) general STRING[50] 1 - -
0x2000:011
(P190.11)
Device data: PU rmware type - (Read only) general STRING[50] 1 - -
0x2000:012
(P190.12)
Device data: PU bootloader version - (Read only) general STRING[50] 1 - -
0x2000:013
(P190.13)
Device data: PU bootloader type - (Read only) general STRING[50] 1 - -
0x2000:014
(P190.14)
Device data: Module - rmware version - (Read only) general STRING[11] 1 - -
0x2000:015
(P190.15)
Device data: Firmware revision number - (Read only) general STRING[50] 1 - -
0x2000:016
(P190.16)
Device data: Bootloader revision number - (Read only) general STRING[50] 1 - -
0x2001
(P191.00)
Device name My Device general STRING[128] 1 PK -
0x2002:004
(P192.04)
Device module: CU type code - (Read only) general STRING[19] 1 - -
0x2002:005
(P192.05)
Device module: PU type code - (Read only) general STRING[19] 1 - -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
