When the unwinding direcon is overcompensated for, the unwinder will be
un
winding faster than the downstream process can accept, as a result of which
slack will develop in the material.
How to congure the acceleraon compensaon:
1.Set the acceleraon torque in the unwinding direcon with a factor < 100 % in the parame-
ter Evaluaon acceleraon torque negave. 40x5051:123
2.Set the acceleraon torque in the rewinding direcon with a value > 100 % via the parame-
ter Evaluaon acceleraon torque posive. 40x5051:122
Dierent mass ineras which result e.g. from dierent material widths or material densies
are taken into account in the form of a percentage via the parameter Moment of inera
adapon. 40x5051:119
The acceleraon compensaon is enabled via the control bit 26 = TRUE. 40x5050:010 Bit 26
Parameter
Address Name / seng range / [default seng] Info
0x5051:009 Actual line velocity
•
R
ead only: x.xxxx mm/s
The parameter is resolved with 4 decimal posions. The parameter has
the unit [mm/s].
0x5051:096 Actual diameter
•
Read only: x.xxxx mm
The parameter is resolved with 4 decimal posions. The parameter has
the unit [mm].
0x5051:110 Actual moment of inera
•
R
ead only
The parameter is only shown.
0x5051:111 Constant moment of inera
1.0000000000 ... [1.0000000000] ...
2147483647.0000000000
The parameter has the unit [kgcm
2
].
0x5051:112 Max. moment of inera
1.0000000000 ... [10.0000000000] ...
2147483647.0000000000
0x5051:119 Moment of inera
adapon
0.00 ... [100.00] ... 100.00 %
The parameter is resolved with 2 decimal posions. The parameter has
the unit [%].
0x5051:120 Filter me acceleraon compensaon
0.000 ... [0.005] ... 10.000 s
The parameter is resolved with 3 decimal posions. The parameter has
the unit [s].
0x5051:121 Acceleraon torque dead me
0.00 ... [0.10] ... 21474836.47 Nm
The parameter is resolved with 2 decimal posions. The parameter has
the unit [Nm].
0x5051:122 Evaluaon acceleraon torque posive
0.00 ... [105.00] ... 200.00 %
The parameter is resolved with 2 decimal posions. The parameter has
the unit [%].
0x5051:123 Evaluaon acceleraon torque negave
0.00 ... [95.00] ... 200.00 %
0x5051:124 Acceleraon compensaon set torque
•
Read only: x.xx Nm
The parameter is resolved with 2 decimal posions. The parameter has
the unit [Nm].
0x5051:125 Eecve acceleraon compensaon set torque
•
Read only: x.xx %
The parameter is resolved with 2 decimal posions. The parameter has
the unit [%].
Conguring the "Winder Dancer" TA
Acceleraon
compensaon
