The parameter Speed c
ontrol adapon min. value denes the smallest evalua-
on factor. 40x5051:031
Seng the bit 29 = TRUE in parameter Control word enables the speed controller adjustment.
If reels are used that exhibit dierent moments of inera despite having the same diameter
due to e.g. dierent material densies and material widths, this must be taken into account
when adjusng the speed controller. This is done by using the mulplicave evaluaon of the
current adjustment factor: Speed controller gain adapon. 40x5051:029
In this case, a value of 100.00 [%] corresponds to an evaluaon of 1 at the maximum moment
of inera.
The adjustment factor is output in the parameter Speed controller actual gain. 40x5051:032
0.00
0.20
0.40
0.60
0.80
1.00
1.20
0
50 100 150 200 250 300 350
② ③①
D [mm]iameter
Value [%]
Fig. 56: Example: Characteriscs for the adjustment of the gain depending on the selected mode
1 Mode:
Inera
2 Mode: DiamToSquare
3 Mode: Diam
Conguring the "Winder Dancer" TA
Adapng the speed controller gain
