8. Firmware Upgrade UMX-TPS-TX100 series – User's Manual 103
Discovering the Devices
Device discovery is in progress in LDU2
Device List
Legend of the Icons
Icon Name Description
Identify the device
Clicking on the icon causes all front panel LEDs blink in
green for 10 seconds. The feature helps to identify the
device itself in the rack shelf.
IP address editor
To modify IP address settings quickly it is not necessary to
by clicking the pencil icon beside the IP address.
Further information available
Device is unreachable. Change the IP address using the
front panel LCD menu or the IP address editor of the LDU2.
Service mode
upgrade procedure can be continued in this mode.
