1.8 Acoustic Signalling
SOUND MEANING
REPEATED BEEP: 0,6s sound / 2,6s silence STOP error (all STOP buttons are disabled)
BEEP lasting 0,3s actuator stopped after overcurrent
a button of a locked function was pressed
adjustment to the Extra Low Position started
transition from tilt (lateral tilt, Trendelenburg, Reverse-Trende-
lenburg) to horizontal position
REPEATED BEEP during 3 minutes: 1,1s sound / 1,1s
silence
Brake Signal: acoustic signal indicating the bed is not braked
when plugged into the mains (only version with Brake Signal)
1.9 Visual Signalling
FOOT CONTROL LOCK LED INDICATOR (3) MEANING
lit (ON) locked function
not lit (OFF) unlocked function
ashing once per second unlocked function but in the mode of lock selection
ashing 4 times per second locked function but in the mode of lock selection
MAINS POWER LED INDICATOR (1) MEANING
lit (ON) when bed is plugged into the mains bed is mains powered
not lit (OFF) bed is not mains powered
ashing: 0,5s lit / 0,5s not lit control unit overheated
ashing: 0,05s lit / 0,05s not lit calibration mode
ACCUMULATOR CHARGE STATUS LED INDICATOR (2) MEANING
lit (ON) when bed is plugged into the mains accumulator fault: accumulator not connected or low voltage
not lit (OFF) when bed is plugged into the mains accumulator works correctly
ashing (0,2s lit / 1,6s not lit) when bed is plugged into the
mains
accumulator is charging
ashing (1,6s lit / 0,2s not lit) when bed is only accumula-
tor powered
accumulator low
not lit (OFF) when bed is only accumulator powered accumulator works correctly
ashing: 0,05s lit / 0,05s not lit calibration mode
