Fig. Mobi Pad
1 2 1 2
1. Mattress Support Platform
Down (+ Extra Low Position for Essenza
300 with Lateral Tilt)
2. Mattress Support Platform Up
12.8 Lateral Tilt Foot Control
12.9 Mobi Pad
Fig. Lateral Tilt Foot Control
1
234
1. Protection Frame against Unwanted Activation
2. Tilt Right Pedal
3. Emergency CPR Position Pedal
4. Tilt Left Pedal
The foot control is optional and allows setting the Lateral Tilt of the bed with one’s feet.
Ensure that exclusively trained nursing sta󰀨 operates the Lateral Tilt Foot Control.
The use of Lateral Tilt Foot Control is described in the chapter Bed Positioning (see „13 Bed Positioning“ on the page 79).
Press the selected pedal twice in 3 seconds:
► Bed Height Foot Control is activated for
30s after this procedure.
Patient is allowed to use the Mobi Pad only if hospital personnel had assessed that the patient´s physical and psychological state
is in accordance with use of this control element and only if the hospital personnel had trained the patient in accordance with these
instructions for use.
The use of the Mobi Pad is described in the chapter Bed Positioning (see „13 Bed Positioning“ on the page 79).
To disable bed positioning functions for patient, use:
► Attendant Control Panel for Essenza 300 with Lateral Tilt
► Attendant Control Panel for Essenza 300
► Siderail Control Panel for Essenza 300 with Lateral Tilt
► Siderail Control Panel for Essenza 300
