LINET Essenza 300

To Next Page

To Previous Page

D9U001EZ3-0101_0080

13.1 Backrest Adjustment

To adjust Backrest, use:

► Attendant Control Panel for Essenza 300 with Lateral Tilt

► Attendant Control Panel for Essenza 300

► Siderail Control Panel for Essenza 300 with Lateral Tilt

► Siderail Control Panel for Essenza 300

► Handset Control Panel

► Patient Control Panel

Buttons intended for Backrest adjustment:
