17.1 Lifting Pole
WARNING!
Risk of injury due to incorrect use!
► Ensure the Lifting Pole is correctly inserted to a bushing for Lifting Pole in inner corners of the mattress supp-
ort platform at bed head end!
► Ensure the Lifting Pole is xed above the mattress support platform to avoid any risk of the bed tipping over!
Lifting Pole is intended for supporting a patient who uses it to sit or lift by himself / herself or with the help of a caregiver.
Standard Lifting Pole is not compatible with the Essenza 300 with Lateral Tilt or with Accessory Adaptor.
Lifting Pole must be placed into a bushing at head end of the mattress support platform.
Maximum Load of the Lifting Pole is 75 kg.
To ensure safe use of the Lifting Pole:
► Never exceed the maximum load of 75 kg.
► Avoid collision between Lifting Pole and the Head Board during Backrest adjustment or tilting to the Trendelenburg Positi-
on.
► Never use the Lifting Pole for demanding rehabilitation exercises.
► To prevent the bed from tipping over, ensure that the Lifting Pole does not project out from the bed.
To install the Lifting Pole:
► Insert Lifting Pole into a bushing at head end of the mattress support platform.
► Ensure the Lifting Pole is safely installed above the mattress support platform.
► Ensure the safety pin of the Lifting Pole is locked in a compatible bushing.
► Attach a Triangular Holder with an adjustable strap to the Lifting Pole.
Fig. Lifting Pole in the bushing at head end of
the mattress support platform
Fig. Lifting Pole in the Accessory Adaptor at bed head
end
