8.6.1 Handles and Patient Restraint Points
Variants of Handles / Mattress Holders:
■ in the middle of the Backrest upper part and on the sides of the Backrest upper part
■ on the sides of the Calfrest lower part (conguration not compatible with Mobi-Lift)
Variants of Patient Restraint Points:
■ on the sides of the Backrest lower part
■ on the sides of the Thighrest upper part
■ on the sides of the Calfrest lower part (conguration compatible with Mobi-Lift)
■ on the sides of the Calfrest upper part
■ on the sides of the Calfrest upper part and on the sides of the Calfrest lower part
Fig. Potential equalisation female co-
nnector
Fig. Potential equalisation male connector at head end of the bed
DANGER!
Danger to life due to electric shock!
To protect patient against static electric shock:
► Connect potential equalisation male connector to the potential equalisation female connector.
8.7 Potential Interconnection (optional)
