Chapter 6. Panel Editor
6-90
6.12.1 Wiring with PC
- The program edited in the Panel Editor is downloaded or uploaded through the RS-232C port.
- RS-232C port can be connected with PC for the program edited in the Panel Editor or other communication device by
communication.
6.12.2 Download/Upload
Downloads/Uploads a created project at the XGT Panel.
Downloads various files drawn from the Panel Editor to the XGT Panel or uploads from the XGT Panel to the Panel Editor.
Items Description
Screen Downloads/Uploads screens.
Parameter
Downloads/Uploads files related with Parameter, Alarm, Calculation, Block Communication
and Reservation.
Menu Downloads/Uploads text files related with the XGT Panel Menu and English Font.
Select all Downloads/Uploads all.
To Next Page
