Chapter 8. Communication Driver
8-10
8.5 LS MASTER-K Series (10S/30S/60S/100S) : Dedicated Protocol
8.5.1 Communication Mode
Connection is available through LS MASTER-K10/30/60/100S PLC and the Dedicated Protocol.
If connected with LS MASTER-K10/30/60/100S and the Dedicated Protocol, its applicable communication setting is as follows.
At this moment, the applicable communication setting of PLC and the XGT Panel to be connected between should be set identical
to each other.
Setting Contents
Setting Item
CH 1 CH 2
Remarks
Communication
Mode
RS-232C
(232/485converter necessary)
RS-422, RS-485
-
Instrument Sided
Connector
2-Pin connector
-
Connection
Protocol
MASTER-K Dedicated Protocol
-
Communication
Speed
1,200/2,400/4,800/9,600/19,200bps
-
Data Bit 8Bits
-
Parity Bit None
-
Stop Bits 1 Bit
-
Station No.
0 ~ 31(H’1F)
Station No. unavailable if
identical to the XGT Panel
8.5.2 Connection Available device
The range of the connection available device if connected with MASTER-K10/30/60/100S is as follows.
Max. range of the connection available device is diverse based on the connected type of PLC.
Max. available range is displayed in here. For more information on the Max. device range of each PLC, refer to the user’s
manual of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
D Area -
D000 –D255 D000 –D254
Bits Read
unavailable
T Area
T0 –T127 T0 –T127 T0 –T126
-
C Area
C0 –C127 C0 –C127 C0 –C126
-
P Area
P00 –P5F P00 –P05 P00 –P04
Ex.) P0F :
P0’s bit 15
M Area
M00 –M31F M00 –M31 M00 –M30
-
L Area
L00 –L15F L00 –L15 L00 –L14
-
K Area
K00 –K15F K00 –K15
K00 –K14
-
F Area
F000 –F15F F000 –F015
F000 –F014
Read dedicated
S Area -
S00 –S31
S00 –S30
Bits Read
unavailable
