LSIS XP10BKB/DC User Manual

Chapter 6. Panel Editor
6-60
Total X-axis time = (Sampling time) x (Sampling number) = 5 x 10 = 50 sec.
6.9.7 Pie Graph Tag ( )
Displays current value of the devices as a shape of pie graph.
Various starting angle and displaying angle size can be specified as shown below.
0 5 10 15 20 25 30 35 40 45 50
Time (sec.)
Value
50
40
30
20
10
