LSIS XP10BKB/DC User Manual

Appendix 1. System Memory
App-1
Appendix 1. System Memory
Address Name Description Remark
0~899
User memory
900
RTC_C_Y Year of RTC BCD
901
RTC_MON
Month of RTC
BCD
902 RTC_DAY
Day of RTC
BCD
903
RTC_HOUR
Hour of RTC
BCD
904 RTC_MIN
Minute of RTC
BCD
905
RTC_SEC
Second of RTC
BCD
906
RTC_WEEK The day of week (Sunday: 0 – Saturday: 6) BCD
907
SCAN_MIN Stores the minimum scan time. ms
908 SCAN_MAX Stores the maximum scan time. ms
909
SCAN_CUR Stores the current scan time. ms
910
HMI_TYPE Stores the type of XGT Panel (A Type: 0, B Type: 1).
911 HMI_VER Stores the version of XGT Panel.
912 VER_CY Stores the year of O/S.
913
VER_MD Stores the month and date of O/S.
914 CUR_SCR Stores the number of current screen.
915
RESERVED -
916
COM1_COUNT Stores the error count of channel 1.
917
COM1_ERROR Stores the current error code of channel 1.
918
COM2_COUNT Stores the error count of channel 2.
919
COM2_ERROR
Stores the current error code of channel 2.
920
KEY_ESC Stores the status of ESC key.
Lowest bit
921
KEY_ALM Stores the status of ALM key.
Lowest bit
922
KEY_UP Stores the status of ▲ key.
Lowest bit
923
KEY_DOWN Stores the status of ▼ key.
Lowest bit
924
KEY_LEFT
Stores the status of ◀ key.
Lowest bit
925
KEY_RIGHT
Stores the status of ▶ key.
Lowest bit
