Chapter 8. Communication Driver
8-33
8.16 Fuji Inverter FVR-E11S
8.16.1 Communication Mode
Connection is available with Fuji Inverter FVR-E11S.
If connected with FVR-E11S, its applicable communication setting is as follows.
At this moment, the applicable communication setting of the inverter and the XGT Panel to be connected between should be set
identical to each other.
Setting Contents
Setting Item
Ch2
Remarks
Communication
Mode
RS-485
Ch1
Unavailable
Instrument Sided
Connector
RJ45 connector -
Connection
Protocol
Fuji Inverter Protocol -
Communication
Speed
1,200/2,400/4,800/9,600/19,200bps -
Data Bit 8Bits, 7Bits -
Parity Bit
None, Odd, Even
-
Stop Bits
1 Bit, 2 Bits -
Station No.
1 ~ 31
-
8.16.2 Connection Available device
The Function Code Area with Read/Write available with the XGT Panel connected is as shown below.
Max. range of the connection available device is diverse based on the connected type of PLC.
Max. available range is displayed in here. For more information on the Max. device range of each PLC, refer to the user’s
manual of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
F Area -
F0 – F42
-
E Area -
E1 – E42
-
C Area
-
C1 –C33 -
P Area -
P1 – P10
-
H Area -
H1 – H46
-
A Area -
A1 – A19
-
M Area -
M1 – M48
-
S Area -
S1 – S11
-
-
To Next Page
