Chapter 8. Communication Driver
8-19
8.9 LS Inverter : Dedicated Protocol
8.9.1 Communication Mode
Connection is available through the LS inverter and the Dedicated Inverter Protocol.
If connected with the LS inverter and the Dedicated Inverter Protocol, its applicable communication setting is as follows.
At this moment, the applicable communication setting of the inverter and the XGT Panel to be connected between should be set
identical to each other.
Setting Contents
Setting Item
CH 1 CH 2
Remarks
Communication
Mode
RS-232C RS-422, RS-485 -
Instrument Sided
Connector
Terminal plate or connector -
Connection
Protocol
LS inverter Dedicated Protocol -
Communication
Speed
1,200/2,400/4,800/9,600/19,200bps -
Data Bit 7Bits, 8Bits -
Parity Bit None, Even Bit, Odd Bit -
Stop Bits 1 Bit, 2 Bits -
Station No. 0 ~ 31
Station No.
unavailable if
identical to XGT
Panel
8.9.2 Connection Available device
The range of the connection available device if connected with the Dedicated Inverter Protocol is as shown below.
Connection Available Area
Device
Bit Word Long
Remarks
- -
H’0000 –H’FFFF H’0000 –H’FFFE
Bits Read
unavailable
To Next Page
