Chapter 3. General Specifications
3-2
3.2 Performance Specifications
The following table shows the performance specifications of the XGT Panel
Specifications
Item
XP10BKA/DC XP10BKB/DC
References
Screen Size 4.1”
Screen resolution 192 x 64
5VDC DC 4.9 ~ 5.1V (RS-232C port)
24VDC DC 21.6 ~ 26.4V (DC Power Input connector)
Input
voltage
Consumption
current
Less than 200mA (24VDC)
Display LED back-light (192 x 64 Dots)
Communication interface RS-232C, RS-422/485
Can be used
independently
Flash memory 256K bytes
Language Default: English, Can be switched to Korean/Chinese/Russian
RTC None Supports
Download specification 115,200bps (memory division download method per each part)
Keys
12 Keys (F1~F4, ESC, ALM, ▲, ▼,◀,▶, SET, ENT)
System area S000 ~ S899 (900 Word)
Latch area setting
available for
XP10BKB/DC type
System
memory
System flag S900 ~ S999 (100 Word)
Standard certification UL/CE
Dimension(mm)
150 x 93 x 35
Panel cut(mm)
141 x 87
Mass(kg)
0.4
