Chapter 6.
Panel Editor
6-8
This section describes the Screen Edit Window.
6.3.1 Scre
en Edit Window
1) View Screen Edit Wind
ow
(1)
Select screen to edit, and then screen is displayed.
(2)
Multi-layer edit is available.
6.3 Screen Edit Window
It is activated when the item is selected.
46
