LSIS XP10BKB/DC User Manual

Chapter 8. Communication Driver
8-27
8.13 Koyo Direct Logic06 : DirectNet
8.13.1 Communication Mode
Connection is available through Direct Logic 06 and DirectNet of Koyo.
If connected with Direct Logic 06, its applicable communication setting is as follows.
At this moment, the applicable communication setting of DL06 and the XGT Panel to be connected between should be set
identical to each other.
Setting Contents
Setting Item
CH 1 CH 2
Remarks
Communication
Mode
RS-232C RS-422, RS-485 -
Instrument Sided
Connector
RJ-12 Phone Plug 15-Pin SVGA D-Sub -
Connection
Protocol
Direct Net protocol -
Communication
Speed
9,600bps(fixed) 300/600/1,200/2,400/9,600/19,200/38,400bps -
Data Bit 8Bits -
Parity Bit Odd (fixed)
None, Odd, Even
-
Stop Bits
1 Bit
-
Station No. 1 (fixed)
1 ~ 31
-
8.13.2 Connection Available Device
The range of the Read/Write available device with the XGT Panel connected is as shown below.
For more information on the device address, refer to the user’s manual of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
X Area
X0 –X777 X0 – X37 X0 – X36
Y Area
Y0 –Y777 Y0 – Y370 Y0 – Y36
C Area
C0 –C1777 C0 – C77 C0 – C76
SP Area
SP0 –SP777 SP0 – SP37 SP0 – SP36
T Area
T0 – T377 T0 – T377 T0 – T376
CT Area
CT0 – CT177 CT0 – CT177 CT0 – CT176
S Area
S0 – S1777 S0 –S77 S0 –S76
GX Area
GX0 – GX3777
GX0 – GX177 GX0 – GX176
GY Area
GY0 – GY3777
GY0 – GY177 GY0 – GY176
V Area - V0 - V41237 V0 - V41236
-
