Chapter 1. General
1-2
1.2. Features
1.2.1 Features of XGT Panel
(1) Increased application design flexibility through wide graphic LCD (192× 64 dot)
(2) Slim design which considers a user's convenience
(3) Supports two communication channels independently (RS-232C, RS-422/485),
(supporting N:M communication)
(4) Built-in 512K bytes Flash-Memory
(5) O/S and font download system for an upgrade
(6) Provides various tags and drawing functions
(7) Supports multi-languages: Korean, English, Chinese, Russian and others will be provided hereafter
(8) Provides Window-based monitoring software (Panel Editor)
(9) Provides 1000 words of system memory area
(10) 2 kinds of power supply:
- You can connect the external 24VDC through a power supply terminal.
- The 5VDC power can be supplied directly through a communication port (RS-232C)
(Available on LS PLC)
(11) Supports very high communication speed (maximum of 115,200 bps, HEX communication)
– Improved up/download speed
(12) Provides user defined function keys for each screen: F1~F4, , , ,
(13) Provides built-in RTC function (available on XP10KB/DC only)
(14) Each memory area can be up/downloaded in part
(15) Supports two kinds of password (for up · downloading/ data writing)
(16) Supports user defined bitmap input function
(17) Supports bitmap text in various fonts and sizes
(18) Provides various communication drivers
