Chapter 6. Panel Editor
6-44
5) Data
(1) Max. value: will be active only ifWrite Enabledis selected, where the max. value available to input should be set.
Any value more than the set maximum can not be input.
The range available to set is as shown in the table below.
(2) Min. value: will be active only ifWrite Enabledis selected, where the min. value available to input should be set.
Any value less than the set minimum can not be input.
Data
Display
Format
Type
Range
Signed -32,768 ~ 32,767
Word
Unsigned 0 ~ 65,535
Signed
-2,147,483,648 ~ 2,147,483,647
DEC
Long
Unsigned
0 ~ 4,294,967,295
Word 0 ~ FFFF
HEX
Long 0 ~ FFFFFFFF
Word 0 ~ 9999
BCD
Long 0 ~ 99999999
(3) Write Enabled: allows the value to change with the key in the XGT Panel.
Whenever the SET key is pressed, it searches for the tag whereWrite Enabledis selected in the
present screen and displays the cursor in sequence. The display sequence of the cursor is from the left
upper to the right bottom of the screen. In order to change the value, use the left/right direction keys
(W,X), moving the number of ciphers, change the value with the up/down direction keys (S,T) and
then press the ENT key to write the set value on the applicable address. The set value will not be set if
not appropriate.
(4) Signed: will be active only if the display type is of the decimal system, allowing the negative number to be displayed.
(5) Use Password: will be active only ifWrite Enabledis selected. If Use Password is selected and a password is set to
the XGT Panel at the same time, the cursor will not be displayed despite the set key pressed.
The tag which has set Use Password is available to write only if the password is cancelled in the XGT
Panel.
(6) Word/Long: sets the data type of the tag.
Word: 2 bytes, Long: 4 bytes
