6-112
6.16.4 Increment
Increases the value of device as specified value when the function key is pushed.
1) Address
(1) Specifies the address of a device to drive.
(2) Refer to the section ‘6.9.1 Numeric Tag’ for details.
2) Value input
(1) The value of specified device is increased as this value, when the function key is pushed.
3) Data/format
(1) Refer to the section ‘6.9.1 Numeric Tag’.
(2) For increment function, data type should be unsigned type.
4) Apply To All Screens
(1) Applies the function of this function key to all screens identically if selected.
(2) Makes the function selection menu inactive of the applicable function key on the other screens if selected, and its setting will
be unavailable if not released from Apply to All Screens.
(Ex) If the user presses F2, setting window is displayed in the Panel Editor. In the XGT Panel, if the user presses F2, data of D0
increase as many as 10. At this time, data type is unsigned decimal 16 bit data.
