Chapter 8. Communication Driver
8-35
8.17 LS XGK series Loader Protocol
8.17.1 Communication Mode
Connection is available through XGK series of PLC and the Loader Protocol.
Since Communication Speed and Communication Set are fixed, LS XGK series of Loader if selected makes the Communication
Setting button inactive, thus setting is unavailable.
Setting Item Setting Contents Remarks
Communication Mode RS-232C CH2 Unavailable
Instrument Sided Connector 9pin Male connector -
Connection Protocol XGK Loader Protocol -
Communication Speed 115,200bps
Data Bit 8Bits
Parity Bit None
Stop Bits 1 Bit
Station No. None
Fixed (Setting unavailable)
8.17.2 Connection Available Device
Device range of LS XGK series of PLC where Read or Write is available with the XGT Panel connected to is as follows.
Max. range of the connection available device is diverse based on the connected type of PLC.
Max. available range is displayed in here. For more information on the Max. device range of each PLC, refer to the user’s manual
of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
P Area P00000 - P2047F P0000 - P2047 P0000 - P2046
EX) PD0000F :
P0’s bit 15
M Area M00000 - M2047F M0000 - M2047 M0000 - M2046 -
K Area
K00000 - K2047F K0000 - K2047 K0000 - K2046 -
F Area F00000 - F2047F F0000 - F2047 F0000 - F2046 Read dedicated
T Area T0000 - T2047 T0000 - T2047 T0000 - T2046 -
C Area C0000 - C2047 C0000 - C2047 C0000 - C2046 -
U Area U00.00.0 - U7F.31.F U00.00 - U7F.31
U00.00 - U7F.30
-
S Area S00.00 - S127.99 -
-
Bits Read
unavailable
L Area L000000 - L11263F L00000 - L11263
L00000 - L11262
-
N Area - N00000 - N21503
N00000 - N21502
-
D Area D00000.0 - D32767.F D00000 - D32767
D00000 - D32766
-
ZR Area - ZR00000 - ZR65535
ZR00000 - ZR65534
-
To Next Page
