8.14 NAIS FP series : Mewtocol
8.14.1 Communication Mode
Connection is available through FP series of PLC and Mewtocol of NAIS.
If connected with FP series, its applicable communication setting is as follows.
At this moment, the applicable communication setting of FP series and the XGT Panel to be connected between should be set
identical to each other.
Setting Contents
Setting Item
Tool Port CH1/CH 2
Remarks
Communication
Mode
RS-232C RS-232C,RS-422, RS-485 -
Instrument Sided
Connector
Mini Din 5-Pin connector
5-Pin connector -
Connection
Protocol
Mewtocol -
Communication
Speed
9,600bps(fixed) 2,400/9,600/19,200/38,400/57,600/115,200bps -
Data Bit 8Bits 7Bits, 8Bits -
Parity Bit Odd (fixed)
None, Odd, Even
-
Stop Bits
1 Bit 1 Bit, 2Bits
Station No.
1 ~ 31 1 ~ 31
-
8.14.2 Connection Available Device
The range of the Read/Write available device with the XGT Panel connected is as shown below.
Max. range of the connection available device is diverse based on the connected type of PLC.
Max. available range is displayed in here. For more information on the Max. device range of each PLC, refer to the user’s
manual of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
X Area
X0 –X73F WX0 – WX73 DWX0 – DWX72
Y Area
Y0 –Y73F WY0 – WY73
DWY0 – DWY72
R Area
R0 –R97F
WR0 –WR97 DWR0 –DWR96
L Area
L0 –L63F WL0 – WL63 DWL0 – DWL62
T Area
T0 – T1023
C Area
C0 – C1023
EV0 – EV1023 DEV0 –DEV1022
D Area -
DT0 –DT32764 DDT0 –DDT32763
R(Special)
R9000 –R910F
- -
LD Area -
LD0 –LD127 DLD0 –DLD126
D(Special) - DT90000 - 90259 DDT90000 - 90258
-
