6-108
6.16 Function Key Settings
The following explains about the function keys.
The XGT Panel offers eight function keys as shown below.
A function can be specified differently on the same function key per screen, and an identical function can be also specified for
all the screens.
Key Description Initial function
User defined function key 1 None
User defined function key 2 None
User defined function key 3 None
User defined function key 4 None
Arrow key (Up) (Can be defined as a function key) None
Arrow key (Down) (Can be defined as a function key) None
Arrow key (Left) (Can be defined as a function key) Go to the previous screen
Arrow key (Right) (Can be defined as a function key) Go to the next screen
Click the key where a function is specified to display the function setting window as below.
To Next Page
