Chapter 8. Communication Driver
8-3
8.2 LS MASTER-K Series (80S/120S/200S/300S/1000S) Loader Protocol
8.2.1 Communication Mode
Connection is available through LS MASTER-K series of PLC and the Loader Protocol.
Since Communication Speed and Communication Set are fixed, LS MASTER-K series of Loader if selected makes the
Communication Setting button inactive, thus setting is unavailable.
Setting Item Setting Contents Remarks
Communication Mode RS-232C CH2 Unavailable
Instrument Sided Connector 9pin Male connector -
Connection Protocol MASTER-K Loader Protocol -
Communication Speed 38,400bps
Data Bit 8 Bits
Parity Bit None
Stop Bits 1 Bit
Station No. None
Fixed (Setting unavailable)
8.2.2 Connection Available Device
Device range of LS MASTER-K series of PLC where Read or Write is available with the XGT Panel connected to is as follows.
Max. range of the connection available device is diverse based on the connected type of PLC.
Max. available range is displayed in here. For more information on the Max. device range of each PLC, refer to the user’s
manual of the applicable PLC.
Connection Available Area
Device
Bit Word Long
Remarks
D Area
D00000 –D4999F D0000 –D4999 D0000 –D4998
Ex.) D0000F :
D0’s bit 15
T Area
T0 –T255 T0 –T255 T0 –T254
-
C Area
C0 –C255 C0 –C255 C0 –C254
-
P Area
P000 –P63F P00 –P63 P00 –P62
-
M Area
M0000 –M191F M000 –M191 M000 –M190
-
L Area
L000 –L63F L000 –L063 L000 –L062
-
K Area
K000 –K31F K000 –K031
K000 –K030
-
F Area
F000 –F63F F000 –F063
F000 –F062
Read dedicated
S Area -
S00 –S99
S00 –S98
Bits Read
unavailable
To Next Page
