LSIS XP10BKB/DC User Manual

Appendix 1. System Memory
App-2
Address Name Description Remark
926
KEY_SET
Stores the status of SET key Lowest bit
927
KEY_ENT
Stores the status of ENT key Lowest bit
928
KEY_F1
Stores the status of F1 key Lowest bit
929 KEY_F2
Stores the status of F2 key Lowest bit
930
KEY_F3
Stores the status of F3 key Lowest bit
931 KEY_F4
Stores the status of F4 key Lowest bit
932
W_ALWAYS_ON Always On (0x0001)
933
W_ALWAYS_OFF Always Off (0x0000)
934
W_SCAN_TOGGLE Scan toggle (0x0001 <-> 0xFFFE)
935 W_FATAL_ERROR Turns on when a severe error has occurred
Lowest bit
936
W_LIGHT_ERROR Turns on when a minor error has occurred.
Lowest bit
937
W_ERROR_KIND Stores the error code
938 W_RTC_DATA_ERROR Stores the error code of RTC
939 W_WDT_COUNT Not used
940 W_20MS 20-ms cycle clock
Lowest bit
941 W_100MS 100-ms cycle clock
Lowest bit
942
W_200MS 200-ms cycle clock
Lowest bit
943
W_1S 1-sec cycle clock
Lowest bit
944
W_2S 2-sec cycle clock
Lowest bit
945
W_10S 10-sec cycle clock
Lowest bit
946
W_20S 20-sec cycle clock
Lowest bit
947
W_60S 60-sec cycle clock
Lowest bit
948
WDT_PTR_H The high address of WDT error
949
WDT_PTR_L The low address of WDT error
950
CALC_L_ERR
The error flag of calculation (divided by zero)
Each bit response to 0~15 calculation
Calculation 0 ~ 15
951
CALC_H_ERR
The error flag of calculation (divided by zero)
Each bit response to 16~19 calculation
Calculation 16~19
952~999 RESERVED -
