Chapter 6. Panel Editor
6-48
(2) If W key is pressed, the cursor will ascend to 10 digits.
Key Display Remarks
W
1 2 3
4
5
Number of the digits ascended (Cursor blinks)
(3) If X key is pressed, the cursor will descend to 1 digit again.
Key Display Remarks
X
1 2 3 4
5
Number of the digits descended (Cursor blinks)
(4) If S key is pressed, the value on 1 digit will increase by 1, displaying 12346. However, the changed value
is not transferred to PLC yet this moment.
Key Display Remarks
S
1 2 3 4
6
Setting value increased by 1 (Cursor blinks)
(5) If T key is pressed, the value on 1 digit will decrease by 1, displaying 12345. However, the changed value
is not transferred to PLC yet this moment.
Key Display Remarks
T
1 2 3 4
5
Setting value decreased by 1 (Cursor blinks)
(6) If S key is pressed twice again, the value on 1 digit will increase by 2, displaying 12347.
Key Display Remarks
S
1 2 3 4
7
Setting value increased by 2 (Cursor blinks)
(7) If ENT key is pressed, the present setting value of 12347 will be written by D0000 on the PLC. And the
cursor will disappear.
Key Display Remarks
ENT 1 2 3 4
7
Write setting value(Cursor disappears)
- If there is no response from the connection instrument while writing or there is NAK response, Re-Write is
not available. That is, Write is executable just one time.
To Next Page
