3-95
5. Operate the winch lever (3) to the “UP” (pull toward you) side
and winch until the hook block automatically stops (over hoist).
NOTES
Hoisting the hook block too much will result in the detection of
over hoist. Then the alarm buzzer and audible message of “Hook
Over Hoist” are heard and the hook raising operation
automatically stops.
6. With the hook stowing switch at the “ON” position, operate the
winch lever (3) to the “UP” (pull toward you) side again and
slowly raise the hook block (4) to stow the block at the bottom of
the boom end.
NOTES
Operating the hook stowing switch to the “ON” position turns on
the pilot lamp at the switch section.
7. Verify that the boom stowing lamp (1) (green) on the outrigger
display lights up.
NOTES
If the boom stowing lamp (1) (green) on the outrigger display
does not light up, repeat the boom lowering operation to the
lowest position and slewing operation.
