Maeda MC-305C-2 - Rated Total Load Charts

5-6
4. RATED TOTAL LOAD CHART
[1] RATED TOTAL LOAD CHART AT WIRE ROPE 4 FALLS
* The rated total load is a load including the mass of a hoisting accessory (hook: 30kg).
OUTRIGGER EXTENDED TO MAXIMUM
BOOM (1)+(2) BOOM (1)+(2)+(3) BOOM (1)+(2)+(3)+(4) BOOM (1)+(2)+(3)+(4)+(5)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
2.50 2980 2.70 2270 4.00 1080 4.50 790
3.00 2390 3.00 2120 4.50 985 5.00 660
3.50 1990 3.50 1680 5.00 880 6.00 520
4.00 1710 4.00 1440 6.00 770 7.00 430
4.50 1490 4.50 1260 7.00 670 8.00 380
5.00 1340 5.00 1110 8.00 570 9.00 340
5.62 1160 5.50 990 9.00 500 10.00 310
-- -- 6.00 880 9.99 435 11.00 280
-- -- 7.00 730 -- -- 12.16 260
-- -- 7.82 630 -- -- -- --
OUTRIGGER EXTENDED TO MEDIUM
BOOM (1)+(2) BOOM (1)+(2)+(3) BOOM (1)+(2)+(3)+(4) BOOM (1)+(2)+(3)+(4)+(5)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated
total load
(kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
2.50 2980 2.70 2270 4.00 1060 4.50 780
3.00 2360 3.00 2090 4.50 950 5.00 650
3.50 1960 3.50 1680 5.00 860 6.00 500
4.00 1680 4.00 1420 6.00 750 7.00 410
4.50 1380 4.50 1240 7.00 630 8.00 360
5.00 1140 5.00 1070 8.00 490 9.00 320
5.62 950 5.50 950 9.00 410 10.00 290
-- -- 6.00 800 9.99 350 11.00 260
-- -- 7.00 610 -- -- 12.16 250
-- -- 7.82 520 -- -- -- --
OUTRIGGER EXTENDED TO MINIMUM
BOOM (1)+(2) BOOM (1)+(2)+(3) BOOM (1)+(2)+(3)+(4) BOOM (1)+(2)+(3)+(4)+(5)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated
total load
(kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
2.50 2980 2.70 2270 4.00 1060 4.50 780
3.00 2350 3.00 2090 4.50 950 5.00 650
3.50 1800 3.50 1680 5.00 860 6.00 500
4.00 1430 4.00 1370 6.00 680 7.00 410
4.50 1140 4.50 1120 7.00 530 8.00 360
5.00 950 5.00 910 8.00 420 9.00 320
5.62 790 5.50 790 9.00 340 10.00 290
-- -- 6.00 670 9.99 300 11.00 240
-- -- 7.00 510 -- -- 12.16 210
-- -- 7.82 430 -- -- -- --
