6-14
[13] GRIP (13)
The Transmitter is designed for one hand controls in general.
Levers and buttons can be manipulated by your thumb, while the
accelerator lever can be triggered by your forefinger. Other fingers
should grab the grip to hold the Transmitter.
[14] CONNECTION CABLE (14)
The connection cable is a cable between the Transmitter and
Receiver.
Before and after the operation, always check this connection cable
for any crack or damage, or bent. In addition, check the receptacle
for any damage.
[15] STORAGE CASE (15)
The Storage case is a compact bag for protection of the
Transmitter.
Before putting it into this case, ensure that the power of the
Transmitter is OFF.
[16] HOOK BELT (16)
During the operation, this belt prevents the Transmitter from falling
down to the ground, when the operator drops it by mistake.
Hook one end of the hook belt (16) to the Transmitter and attach
another end to the operator’s waist belt, or such.
