6. Insert the position pin (4) through the hole of bracket (3), and
secure it with the snap pin (5) to the tip of position pin (4).
Always secure the position pin (4) with the snap pin (5). If
the snap pin falls out during operations, serious injury or
damage to the machine may result.
7. Attach the load securely to the hook (1) and start operations.
Always work in accordance with all appropriate local
regulations concerning your own and others’ safety.
