9-18
6. WORKING RANGE AND RATED TOTAL LOAD
• When using the searcher hook, be sure to set searcher hook mode for moment limiter.
• Fall mode/option mode and searcher hook position must be set as “850kg searcher hook mode”
when 850kg searcher hook is used. Searcher hook position must be displayed on moment limiter
boom length window.
• Never use the searcher hook and the crane hook simultaneously.
6.1 WORKING RANGE DIAGRAM FOR SEARCHER HOOK
