Magtrol DSP7000 User Manual

7
Magtrol Model DSP7000 Dynamometer Controller
Chapter 1 – Introduction
GENERAL
INFORMATION
6
DSP7000
MAGTROL
System Configurations
DSP7002 Connected to Eddy-Current and Powder Brake Dynamometer (Tandem Setup)
USB
PC
M-TEST
Clutch
(EK)
DSP
7002
Dynamometer
Controller
Transformer
Powder Brake
Dynamometer (PB)
Excitation
Torque
DES Power Supply
TSC 401
Torque/Speed
Conditioner
Eddy-Current Brake
Dynamometer (WB)
Excitation
Torque
TSC 401
Torque-Speed
Conditioner
DES Power Supply
Speed
DSP7002 Connected to 2 Eddy-Current or 2 Powder Brake Dynamometers (Tandem Setup)
Powder Brake (PB)
Dynamometer
Eddy-Current (WB)
Dynamometer
Excitation
Torque
Speed
TSC 401
Torque-Speed Conditioner
DES Power Supply
Powder Brake (PB)
Dynamometer
Eddy-Current (WB)
Dynamometer
Excitation
Torque
Speed
TSC 401
Torque-Speed Conditioner
DES Power Supply
USB
PC
M-TEST
OR
DSP 7002
DYNAMOMETER CONTROLLER
TheUSBDriverrequiredforcommunicationbetweenthePCandDSP7000isavailablefor
downloadatMagtrol’swebsite:
www.magtrol.com/support/downloads.html
