Magtrol Model DSP7000 Dynamometer ControllerChapter 1 – Introduction
GENERAL
INFORMATION
7
DSP7000
MAGTROL
custOM MOtOr test systeM
TheDSPcanbeincorporatedintoaCustomizedMotorTestSystem.ThesePCbased,turn-keysystemsarecustomdesigned
andbuilttomeetspecificuserrequirements.
System Configurations
heavy-duty equipment rack
M-TEST Motor Testing Software
WB Eddy-Current
Dynamometer
DES Power Supply
TSC Torque Signal
Conditioner
AMF Adjustable
Motor Fixture
Dynamometer
Table
HD Hysteresis
Dynamometer
DSP7000 Dynamometer
Controller
6530 Power Analyzer
keyboard
drawer
side panel connectors allow
for easy hook-up
space for rackmounted
third-party power supply
and computer
LCD monitor
emergency stop button
