Manitowoc 16000 Service And Maintenance Manual

Reference Only
Manitowoc Published 05-09-17, Control # 014-28 3-17
16000 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
54-U DO-19 Travel 2-Speed Solenoid 0 Volts Off; 24 Volts On CAN29-3-4
54-V Ground Travel Brake Release Solenoid Ground
54-W DO-20 Swing Brake Release Solenoid 0 Volts Off; 24 Volts On CAN29-3-8
54-X Ground Swing Lock Solenoid - In *3 Ground
54-Z DO-21 Swing Lock Solenoid - In *3 0 Volts Off; 24 Volts On CAN29-3-16
54-a Ground Swing Lock Solenoid - Out *3 Ground
54-b DO-22 Swing Lock Solenoid - Out *3 0 Volts Off; 24 Volts On CAN29-3-32
54-c Ground Swing Bearing Auto Lubrication Ground
54-d DO-23 Swing Bearing Auto Lubrication 0 Volts Off; 24 Volts On CAN29-3-64
54-e Ground Crawler Track Rollers Auto Lubrication Ground
54-f DO-24 Crawler Track Rollers Auto Lubrication 0 Volts Off; 24 Volts On CAN29-3-128
54-g Ground Jumper to Node Select 4 Ground
54-m NS-4 Node Select 4 Jumper to Ground 0 Volts (With Jumper)
54-n 24 Volts Swing Motor Speed Sensor 24 Volts Nominal
54-p EC1A Swing Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN53-6 *2
54-r Ground Swing Motor Speed Sensor ground
54-s EC1B Swing Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN53-6 *2
W56 Receptacle – Drum 2, Alarm and Sensors
56-A Ground Load Hoist (Drum 2) Right Side Motor Control Ground
56-B DO-7 Load Hoist (Drum 2) Right Side Motor Control
See
Table 3-2, page 3-8
CAN29-1-64
56-C Ground Load Hoist (Drum 2) Brake Solenoid Ground
56-D DO-8 Load Hoist (Drum 2) Brake Solenoid 0 Volts Off; 24 Volts On CAN29-1-128
56-E Ground Right Side Swing/Travel Alarm Ground
56-F DO-9 Right Side Swing/Travel Alarm 0 Volts Off; 24 Volts On CAN29-2-1
56-G Ground Drum 2 Minimum Bail Ground
56-H DO-10 Drum 2 Minimum Bail 0 Volts Off; 24 Volts On CAN29-2-2
56-J DI-8 Drum 2 Minimum Bail 0 Volts Off; 24 Volts On CAN55-1-128
56-N NS-4 Node Select 4 Jumper to Ground 0 Volts (With Jumper)
56-S 24 Volts Hydraulic Fluid Temperature Sensor 24 Volts Nominal
56-T 24 Volts Engine Fuel Level Sensor 24 Volts Nominal
56-U Ground
Hydraulic Fluid Temperature Sensor/
Jumper to Node Select 4
0 Volts (With Jumper)
56-W Ground Engine Fuel Level Sensor Ground
56-X 24 Volts Hydraulic Fluid Level Sensor 24 Volts Nominal
56-Z Ground Hydraulic Fluid Level Sensor Ground
56-a AI-9 Hydraulic Fluid Temperature Sensor 0 Volts Off; 24 Volts On CAN22-2 *1
56-b AI-10 Engine Fuel Level Sensor 1.8 Volts Full; 4.1 Volts Empty CAN22-4 *1
56-d AI-11 Swing Brake Pressure Sensor 1 V at 0 psi; 5 V at 750 psi
56-f AI-14 Hydraulic Fluid Level Sensor 1.8 Volts Full; 4.1 Volts Empty CAN23-4 *1
56-g 24 Volts Load Hoist (Drum 2) Motor Speed Sensor 24 Volts Nominal
56-j Ground Load Hoist (Drum 2) Motor Speed Sensor Ground
56-m 24 Volts Swing Brake Pressure Sensor 24 Volts Nominal
