Operating elements for driving
3.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 3 - 39
xx.xx.xxxx
Instrument panel
Tachometer
Flame start system monitoring
STOP warning
Engine warning
Engine oil pressure too low
s
Display, engine speed in rpm; Ã p. 4 - 20
–On: Engine not ready to start – is being warmed up
– Off: Engine is ready to start
à p. 4 - 16
–On: Turn engine off as quickly as possible – warning buzzer
sounds, warning message displayed
à p. 5 - 51
–On: Engine off – ignition on
or
Engine on – engine malfunction
– Off: Engine on – no malfunction
à p. 5 - 51
–On: Engine off – ignition on
or
Engine on – oil pressure too low
– Off: Engine on – no malfunction
à p. 5 - 51
