OPERATING PROCEDURES GRT8120 OPERATOR MANUAL
4-160 Published 3-22-2021, Control # 702-02
After the selection procedure, there are three options:
• Cancel input mode:
- Press the button (3, Figure 4-181) or (4) once – the
config menu is opened.
• Switching over the input mode:
- Select and confirm a symbol (1) for the next
component – symbol orange.
• Accept the displayed rigging mode:
- Select and confirm the symbol (2), refer to
Accepting the Rigging Code, page 4-163.
Enter the other components of the current rigging mode in
the same way.
Counterweight
• Select and confirm the symbol (1, Figure 4-182).
• Use the buttons (2) or (3) to select the required
counterweight combination, e.g. 0.0 klb.
• Confirm the selection.
8849-32a
FIGURE 4-181
1
2
10254-48a
8849-33a
FIGURE 4-182
1
1
10254-49a
To Next Page
