RADIATOR
RADIATOR
REMOVAL
/
INSTALLATION
Caution
.
Eetore loosening
the radiator drain
plug,
verlty lhat the radiator d.ain hose tac€s straight
down,
.
Poallion the hose
damp in the
original localion on the hose, and squeeze the
clamp lightly
with large
pliers
to ensure
a
good
tit.
1
Disconnecl
lhe
negatrve
battery
cable.
2. Drain the engine coolant.
3. Remove in the order
shown in the figure.
4.
lnstall
in the reverse
oroer ol removal
r*n
{3o-1
ro cfrrg,
6F95
hrb)
1.
Cooling fan connector
2.
Coolant reservoir hose
3. Radialor hose
4. Oil cooler hose
(ATX)
5. Radiator bracket
6. Radiator
Inspection.....................................
page
E
7
7- Cooling fan
and
radiator
cowling assembly
INSPECTION
Check
for
the
tollowing
and repair or replace as necessary.
1. Cracks, damage, and water leakage.
2. Bent lins
(repair
with a screwdriver).
3. Distoned or bent
radiator
inlet.
Sleps Atter Installation
1. Fill the radiator with the specified amount
and
type
of en-
gine
coolant.
(Refer
to
page
E-4.)
2.
Connect the
negative
battery cable.
3. Start
the
engine
and
check
for leaks.
E-7
