Mazda 121 - 2 Nd Gear, Synchronizer Ring

J
TRANSAXLE
Assembly
note
2nd
gear,
synchronlzer
rino
1.
Asaemble the
2nd
gear
to the secondary
shaft as
shown
in the
figure.
2.
Assemble
the synchronizer
ring.
Clutch
hub as€embly
(lsu2nd), synchronizer
fng
1. Assemble the
clutch hub
assembly
to the secondary
shaft
as shown in
the {igure.
2.
Assemble the
synchronizer
ring.
Caution
.lnstall
the
clutch hub
assembly
(lsi/2nd) wlth a
presa
It necessary.
.
Align
the synchlonizer
drg
gloove
and
leverse
gear
key
groove
when installing.
1st
gear
Assemble the
1st
gear
to the
secondary
shaft as
shown in the
figure.
Caulion
.
Align the synchronizer
ring
groove
and
clutch
hub
assembly
key when
Installing.
Pinion
gear,
bearing
inner race
(lst)
Caution
.
Replace
the bearing
inner
race lf
removed.
1.
Support
the
4th
gear
of
the secondary
shatt.
2.
Inslall the
olain
end ol
pinion gear
with the bonom
up.
3. Set
lhe SST to
the new bearing
inner
race as shown
in the
fagure.
I
&
Y
J-32
