ENGINE STAND MOUNTING
-F
AO
O
I
20mm
(0.79
i
1 . lnstall the SST
(arms)
to the
holes as shown in
the
figure,
and loosely tighten the SST
(bolts).
2. Assemble the SST
(botts
and
plale)
in
the specilied
po-
sition.
3. Assemble the SST
(nuls,
hooks,
and bolts)
4. Install the SST to the respective
arms.
Note
.
Adiust the SST
Oolts)
so
that lea€ than 20mm
(0.79
in) ol thread
is
exposed.
.
Make the SsT
(plate
and arms)
parallel
by adiust-
Ing the SST
(bolts
and
nuis).
5. Tighten the SST
(bolts
and
nuts) to atfix the SST firmly.
6. Mount the engine on the SST
(englne
stand).
