WIRING DIAGRAMS
Page 2D-12
90-826883R2 JUNE 1998
Optional Electrical Accessories Wiring Diagrams
a
b
c
d
e
f
a
-
Manual Start Model with Lighting Coil and Unregulated AC V
oltage
b
-
T
erminal Block
c
-
Manual Start Model with Battery Charging Kit
d
-
Rectifier
e
-
Manual Start Model with V
oltage Regulator
f
-
V
oltage Regulator
121
