Page #57 background imageLoading...
Page #57 background image
IGNITION
Page 2A-12 90-826883R2 JUNE 1998
Ignition Test Procedures
Direct Voltage Adapter (DVA)
WARNING
DANGER -- HIGHVOLTAGE/SHOCKHAZARD! Do nottouch ignition components
and/or metal test probes while engine is running and/or being cranked. STAY
CLEAR OF SPARK PLUG LEADS. To assure personal safety, each individual
spark plug lead should be grounded to engine.
WARNING
When testing or servicing the ignition system, high voltage is present. DO NOT
TOUCH OR DISCONNECT any ignition parts while engine is running, while key
switch is on or while battery cables are connected.
CAUTION
Failure to comply with the following items may result in damage to the ignition
system.
1. DO NOT reverse battery cable connections. The battery negative cable is (-)
ground.
2. DO NOT spark battery terminals with battery cable connections to checkpo-
larity.
3. DO NOT disconnect battery cables while engine is running.
4. DO NOT crank engine with CDI or Ignition Coils not grounded.
CAUTION
To protect against meter and/or component damage, observe the following pre-
cautions:
· 400 VDC* test position (or higher) MUST BE used for all tests.
· INSURE the Positive (+) lead/terminal of DVA is connected to the Positive (+) re-
ceptacle of meter.
· DO NOT CHANGE meter selector switch position while engine is running and/or
being cranked.
· ALL COMPONENTS MUST BE GROUNDED during tests. Running or cranking
engine with CDI or Ignition Coils ungrounded may damage components.
* If using a meter with a built-in DVA, the DVA/400 or DVA/500 VDC test position should
be used.
NOTE: Test leads are not supplied with the Direct Voltage Adapter. Use test leads
supplied with multi meter.
Test procedures and specifications are providedfor checkingprimary ignitionvoltage
while the engine is running and/or being cranked with all harnesses connected.
