CARBURETOR/FUEL
PUMP
Page 3A-8
90-826883R2 JUNE 1998
Carburetor Float Adjustment
1 in. (25.4 mm)
b
a
171
1
1
a-
Carburetor Scale (91-36392)
b-
Measured from bottom of float
52646
a
b
c
d
e
a-
Float
b-
Float Hinge
c-
Float Pin
d-
Bend Float Arm Here to Adjust Float Level
e-
Needle
133
135
