BATTERY CHARGING AND STARTING SYSTEMS
Page 2B-8 90-826883R2 JUNE 1998
Alternator Amperes Output
Amperage output can be measured by installing a 10 ampere (minimum) amp meter in
series between the rectifier and the battery or by clamping an inductive type amp meter
(10 amp minimum) over the RED output lead from the rectifier to the battery.
BLACK Stator (2 Magnet Flywheel)
RPM AMPERES (Approximate)
Idle 0
1000 0
2000 .5
3000 2.2
4000 3.1
5000 3.8
6000 4.0
RED Stator (4 Magnet Flywheel)
RPM AMPERES (Approximate)
Idle 0
1000 0.8
2000 4.1
3000 5.3
4000 5.8
5000 6.1
6000 6.3
