CARBURETOR/FUEL PUMP
90-826883R2 JUNE 1998 Page 3A-3
Carburetor (20/25/JET 20)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 CARBURETOR (WMC-52 - 20HP)
1
1 CARBURETOR (WMC-53 - 25HP)
1
1 CARBURETOR (WMC-44 - 20HP)
1 CARBURETOR (WMC-45 - 25HP)(JET 20)
2
1 THROTTLE VALVE (20HP)
2
1 THROTTLE VALVE (25HP/JET 20)
1 THROTTLE SHAFT (20-WMC-44)
3 1 THROTTLE SHAFT (25-WMC-45)(JET 20)
THROTTLE SHAFT(20/25HP)(WMC52/52A/53/53A)
4 1 FUEL BOWL
5 1 FLOAT
6 1 VALVE–inlet needle
7
1 JET–main fuel (.044 - 20HP)
7
1 JET–main fuel (.076- 25HP/JET 20)
8 1 PLUG–jet retainer 32 3.6
9 1 COVER–diaphragm
10 4 SCREW–diaphragm cover 14 1.6
11 1 BODY–fuel pump
12 5 SCREW–fuel pump cover 18 2.0
13 1 COVER–fuel pump
14 1 COVER–fuel pump (JET 20)
15 1 PLUG 32 3.6
16 1 GASKET/DIAPHRAGM KIT
17 1 REPAIR PARTS KIT
18 1 PLATE–cover (MANUAL)
19 1 ELECTRIC CHOKE (ELECTRIC)
20 2 SCREW–cover plate 18 2.0
21 1 GASKET–carburetor
22 1 DIAPHRAGM/GASKET
23 1 GASKET
24 1 FLOAT PIN
25 1 FLOAT LEVER
26 1 PRIMER/INJECTOR SERVICE KIT (See illustration for contents)
27 1 SCREW
28 1 NUT
